Premier Industrial Pump
| Quantity: | |
|---|---|
Excellent performance,Integral pump structure,require higher accuracy;Procen vanes technology,makes the performance more stble;Ensure the pump system with higher reliability.
Forced lubrication,Built-in gear pump and constant pressure oil supply mechanism forced oil supply,ensure the stable and reliable operation under high suction pressure.
Electric solenoid valve,Maintain system vacuum degree after power-off,prevent the oil suckback.
Compact structure,Integrated design between pump and motor,lighter,smaller,the size is satisfied all kinds of application.
| Displacement speed | 50HZ | m³/h（L/s） | 8.0（2.2） | |
| 60HZ | 9.6（2.7） | |||
| Ultimate partial pressure gas ballast close | Pa | 1*10⁻¹ | ||
| Ultimate total pressure gas ballast close | Pa | 3 | ||
| Ultimate total pressure gas ballast open | Pa | 20 | ||
| Power supply | Single | |||
| Power rating | kw | 0.55 | ||
| Level of protection | IP44 | |||
| Intake and exhaust | KF25 | |||
| Oil capactiy | L | 0.5 | ||
| Motor speed | 50HZ | rpm | 1400 | |
| 60HZ | 1720 | |||
| Ambient temerature | ℃ | 10-40 | ||
| Noise level(50Hz) | dB | ≤65 | ||
| Weight | kg | 17 | ||
| Dimension（L*W*H) | mm | 395*145*257 | ||
Excellent performance,Integral pump structure,require higher accuracy;Procen vanes technology,makes the performance more stble;Ensure the pump system with higher reliability.
Forced lubrication,Built-in gear pump and constant pressure oil supply mechanism forced oil supply,ensure the stable and reliable operation under high suction pressure.
Electric solenoid valve,Maintain system vacuum degree after power-off,prevent the oil suckback.
Compact structure,Integrated design between pump and motor,lighter,smaller,the size is satisfied all kinds of application.
| Displacement speed | 50HZ | m³/h（L/s） | 8.0（2.2） | |
| 60HZ | 9.6（2.7） | |||
| Ultimate partial pressure gas ballast close | Pa | 1*10⁻¹ | ||
| Ultimate total pressure gas ballast close | Pa | 3 | ||
| Ultimate total pressure gas ballast open | Pa | 20 | ||
| Power supply | Single | |||
| Power rating | kw | 0.55 | ||
| Level of protection | IP44 | |||
| Intake and exhaust | KF25 | |||
| Oil capactiy | L | 0.5 | ||
| Motor speed | 50HZ | rpm | 1400 | |
| 60HZ | 1720 | |||
| Ambient temerature | ℃ | 10-40 | ||
| Noise level(50Hz) | dB | ≤65 | ||
| Weight | kg | 17 | ||
| Dimension（L*W*H) | mm | 395*145*257 | ||
